● All specifications written in here subjected to change without notice.

Group Code RoHS,
REACH		 Color Size,Thickness
(mm)		 3.0 5.0 8.0 10.0 12.0 15.0 20.0 25.0 30.0 40.0 Protective film specification Grades
Front Back
FMET 4323・ ✔ Ivory 1,000×2,000 (4) (3) (1) (1)   (1) (1) (1) (1) (1) Note 1 Note 1 Standard
1,212×2,424 (3) (2) (1) (1)             Green FM PE Transparent PE
4773・ ✔ White 500×1,000                   (1) None None
1,000×2,000 (4) (3) (1) (1)   (1) (1) (1) (1) (1) Note 1 Note 1
1,212×2,424 (3) (2) (1) (1)   (1)         Note 1 Note 1
FMRTS 4605 ✔ Transparent 1,000×2,000 (4) (3) (1) (1)             Green FM PE Transparent PE Standard
1,212×2,424 (3) (2) (1) (1)             Green FM PE Transparent PE
FMH 5305 ✔Note 2 Ivory 1,000×2,000 (4) (3) (1) (1)   (1) (1) (1) (1) (1) Note 3 Note 3 Heat-
resistant
1,212×2,424   (2) (1) (1)             Note 3 Note 3
5775 ✔ White 500×1,000                   (1) None None
1,000×1,000                   (1) None None
1,000×2,000 (4) (3) (1) (1)   (1) (1) (1) (1) (1) Note 3 Note 3
1,212×2,424 (3) (2) (1) (1)             Pink FM paper Pink FM paper
FMHS 6650 ✔ Transparent 1,000×2,000 (4) (3) (1) (1) *           Green FM paper/
Transparent PE(adhesive)		 Green FM paper/
Transparent PE(adhesive)		 Heat-
resistant
1,212×2,424 (3) (2) (1) (1) *           Green FM paper/
Transparent PE(adhesive)		 Green FM paper/
Transparent PE(adhesive)
FMND 7605 △ Transparent 1,000×2,000 (4) (3) (1) (1)             Green FM paper/
Transparent PE(adhesive)		 Green FM paper/
Transparent PE(adhesive)		 Heat-resistant/
Static-dissipative
1,212×2,424 (3) (2) (1) (1)             Green FM paper/
Transparent PE(adhesive)		 Green FM paper/
Transparent PE(adhesive)
74602 ✔ Transparent 1,000×2,000 (4) (3) (1) (1)             Brown FM PE Transparent PE Static-
dissipative
1,212×2,424 (3) (2) (1) (1)             Brown FM PE Transparent PE
FMET
4323（1,000×2,000）
Code 4323・
RoHS,REACH ✔
Color Ivory
Size,Thickness
(mm)		 1,000×2,000 3.0 (4)
5.0 (3)
8.0 (1)
10.0 (1)
12.0
15.0 (1)
20.0 (1)
25.0 (1)
30.0 (1)
40.0 (1)
Protective film specification Front Note 1
Back Note 1
Grades Standard
4323（1,212×2,424）
Code 4323・
RoHS,REACH ✔
Color Ivory
Size,Thickness
(mm)		 1,212×2,424 3.0 (3)
5.0 (2)
8.0 (1)
10.0 (1)
12.0
15.0
20.0
25.0
30.0
40.0
Protective film specification Front Green FM PE
Back Transparent PE
Grades Standard
4773（500×1,000）
Code 4773・
RoHS,REACH ✔
Color White
Size,Thickness
(mm)		 500×1,000 3.0
5.0
8.0
10.0
12.0
15.0
20.0
25.0
30.0
40.0 (1)
Protective film specification Front None
Back None
Grades Standard
4773（1,000×2,000）
Code 4773・
RoHS,REACH ✔
Color White
Size,Thickness
(mm)		 1,000×2,000 3.0 (4)
5.0 (3)
8.0 (1)
10.0 (1)
12.0
15.0 (1)
20.0 (1)
25.0 (1)
30.0 (1)
40.0 (1)
Protective film specification Front None 1
Back None 1
Grades Standard
4773（1,212×2,424）
Code 4773・
RoHS,REACH ✔
Color White
Size,Thickness
(mm)		 1,212×2,424 3.0 (3)
5.0 (2)
8.0 (1)
10.0 (1)
12.0
15.0 (1)
20.0
25.0
30.0
40.0
Protective film specification Front None 1
Back None 1
Grades Standard
FMRTS
4605（1,000×2,000）
Code 4605
RoHS,REACH ✔
Color Transparent
Size,Thickness
(mm)		 1,000×2,000 3.0 (4)
5.0 (3)
8.0 (1)
10.0 (1)
12.0
15.0
20.0
25.0
30.0
40.0
Protective film specification Front Green FM PE
Back Transparent PE
Grades Standard
4605（1,212×2,424）
Code 4605
RoHS,REACH ✔
Color Transparent
Size,Thickness
(mm)		 1,212×2,424 3.0 (3)
5.0 (2)
8.0 (1)
10.0 (1)
12.0
15.0
20.0
25.0
30.0
40.0
Protective film specification Front Green FM PE
Back Transparent PE
Grades Standard
FMH
5305（1,000×2,000）
Code 5305
RoHS,REACH ✔Note 2
Color Ivory
Size,Thickness
(mm)		 1,000×2,000 3.0 (4)
5.0 (3)
8.0 (1)
10.0 (1)
12.0
15.0 (1)
20.0 (1)
25.0 (1)
30.0 (1)
40.0 (1)
Protective film specification Front Note 3
Back Note 3
Grades Heat-resistant
5305（1,212×2,424）
Code 5305
RoHS,REACH ✔Note 2
Color Ivory
Size,Thickness
(mm)		 1,212×2,424 3.0
5.0 (2)
8.0 (1)
10.0 (1)
12.0
15.0
20.0
25.0
30.0
40.0
Protective film specification Front Note 3
Back Note 3
Grades Heat-resistant
5775（500×1,000）
Code 5775
RoHS,REACH ✔
Color White
Size,Thickness
(mm)		 500×1,000 3.0
5.0
8.0
10.0
12.0
15.0
20.0
25.0
30.0
40.0 (1)
Protective film specification Front Note
Back Note
Grades Heat-resistant
5775（1,000×1,000）
Code 5775
RoHS,REACH ✔
Color White
Size,Thickness
(mm)		 1,000×1,000 3.0
5.0
8.0
10.0
12.0
15.0
20.0
25.0
30.0
40.0 (1)
Protective film specification Front Note
Back Note
Grades Heat-resistant
5775（1,000×2,000）
Code 5775
RoHS,REACH ✔
Color White
Size,Thickness
(mm)		 1,000×2,000 3.0 (4)
5.0 (3)
8.0 (1)
10.0 (1)
12.0
15.0 (1)
20.0 (1)
25.0 (1)
30.0 (1)
40.0 (1)
Protective film specification Front Note 3
Back Note 3
Grades Heat-resistant
5775（1,212×2,424）
Code 5775
RoHS,REACH ✔
Color White
Size,Thickness
(mm)		 1,212×2,424 3.0 (3)
5.0 (2)
8.0 (1)
10.0 (1)
12.0
15.0
20.0
25.0
30.0
40.0
Protective film specification Front Pink FM paper
Back Pink FM paper
Grades Heat-resistant
FMHS
6650（1,000×2,000）
Code 6650
RoHS,REACH ✔
Color Transparent
Size,Thickness
(mm)		 1,000×2,000 3.0 (4)
5.0 (3)
8.0 (1)
10.0 (1)
12.0 *
15.0
20.0
25.0
30.0
40.0
Protective film specification Front Green FM paper/
Transparent PE(adhesive)
Back Green FM paper/
Transparent PE(adhesive)
Grades Heat-resistant
6650（1,212×2,424）
Code 6650
RoHS,REACH ✔
Color Transparent
Size,Thickness
(mm)		 1,212×2,424 3.0 (3)
5.0 (2)
8.0 (1)
10.0 (1)
12.0 *
15.0
20.0
25.0
30.0
40.0
Protective film specification Front Green FM paper/
Transparent PE(adhesive)
Back Green FM paper/
Transparent PE(adhesive)
Grades Heat-resistant
FMND
7605（1,000×2,000）
Code 7605
RoHS,REACH △
Color Transparent
Size,Thickness
(mm)		 1,000×2,000 3.0 (4)
5.0 (3)
8.0 (1)
10.0 (1)
12.0
15.0
20.0
25.0
30.0
40.0
Protective film specification Front Green FM paper/
Transparent PE(adhesive)
Back Green FM paper/
Transparent PE(adhesive)
Grades Heat-resistant/
Static-dissipative
7605（1,212×2,424）
Code 7605
RoHS,REACH △
Color Transparent
Size,Thickness
(mm)		 1,212×2,424 3.0 (3)
5.0 (2)
8.0 (1)
10.0 (1)
12.0
15.0
20.0
25.0
30.0
40.0
Protective film specification Front Green FM paper/
Transparent PE(adhesive)
Back Green FM paper/
Transparent PE(adhesive)
Grades Heat-resistant/
Static-dissipative
74602（1,000×2,000）
Code 74602
RoHS,REACH ✔
Color Transparent
Size,Thickness
(mm)		 1,000×2,000 3.0 (4)
5.0 (3)
8.0 (1)
10.0 (1)
12.0
15.0
20.0
25.0
30.0
40.0
Protective film specification Front Brown FM PE
Back Transparent PE
Grades Static-dissipative
74602（1,212×2,424）
Code 74602
RoHS,REACH ✔
Color Transparent
Size,Thickness
(mm)		 1,212×2,424 3.0 (3)
5.0 (2)
8.0 (1)
10.0 (1)
12.0
15.0
20.0
25.0
30.0
40.0
Protective film specification Front Brown FM PE
Back Transparent PE
Grades Static-dissipative

*symbol:
Made-to-order product. Please contact us for more information about production lots.

Note 1:
3mm to 10mm thickness　Front: Green FM PE　Back: Transparent PE
15mm to 20mm thickness　Front: Green FM Paper　Back: Green FM Paper
More than 20mm thickness　Front: None　Back: None

Note 2:
Products manufactured from April 2019 onwards comply with the RoHS directive and REACH Regulations.

Note 3:
3mm to 10mm thickness　Front: Pink FM Paper　Back: Pink FM Paper
More than 20mm thickness　Front: None Back: None

・:
The continuous press method is used for FMET plates that are 3mm to 10mm thickness.
The press lamination method is used for FMET plates that are 15mm to 40mm thickness.

△:
It is not compliant only with REACH. (Since January 19,2021)

Detailed description of the Protective film specification

  • Green character printed to PE protective film special to FM Products

    Green FM PE

  • Blue character printed to paper protective film special to FM Products

    Blue FM paper

  • Green character printed to paper protective film special to FM products

    Green FM paper

  • Pink character printed to paper protective film special to FM products

    Pink FM paper

  • Transparent PE protective film(with adhesive)

    Transparent PE(adhesive)

  • Brown character printed to PE protective film special to FM products

    Brown FM PE
