● Test values are a series of test results with 5mm thick specimen and given here without guarantee.

Testing items Unit Standard Grade Transparent Standard Grade Heat Resistant Grade Transparent Heat Resistant Grade Static Dissipative Grade Heat Resistant/Static Dissipative Grade Testing
Method
FMET
4323		 FMET
4773		 FMRTS
4605		 FMH
5305		 FMH
5775		 FMHS
6650		 FMND-
74602		 FMND
7605
Specific Gravity - 1.45 1.45 1.4 1.55 1.58 1.46 1.4 1.46 ISO 1183-1 and -2
Tensile Stress at Yield MPa 58 58 68 63 64 74 68 72 JIS K7161-2-1B/50
Nominal Tensile Strain at Break % 13 13 9 20 28 12 8 14 JIS K7161-2-1B/50
Charpy Impact Strength (Notched) KJ/㎡ 3.8 3.8 1.6 7.2 5 1.6 1.6 1.7 JIS K7111-1 lepA
Flexural Stress MPa 78 78 87 88 84 99 87 93 JIS K7171
Flexural Elasticity MPa 2900 2900 3100 3000 2900 3300 3100 3000 JIS K7171
Temperature of Deflection Under Load (1.8MPa) ℃ 73 73 63 86 94 85 63 85 JIS K7191
Vicat Sofening Temerature(B) ℃ 81 81 71 97 106 94 71 94 JIS K7206
(140℃-55min)
Dimensional Change on Heating		 Vertical % -2* -2* -3 -4 -4 -5 -3 -5 JIS K6745
Horizontal -1* -1* -1 -1 -1 -1 -1 -1
Linear Thermal Expansion Coefficient ×10-5・K-1 6.7 6.7 6.4 6.5 6.5 6.1 6.4 6.1 JIS K7197
Total Light Transmission % 78 71 75 63 JIS K7361-1
Specific Gravity
Unit -
Standard Grade FMET 4323 1.45
FMET 4773 1.45
Transparent Standard Grade FMRTS 4605 1.4
Heat Resistant Grade FMH 5305 1.55
FMH 5775 1.58
Transparent Heat Resistant Grade FMHS 6650 1.46
Static Dissipative Grade FMND-74602 1.4
Heat Resistant/Static Dissipative Grade FMND 7605 1.46
Testing Method ISO 1183-1 and -2
Tensile Stress at Yield
Unit MPa
Standard Grade FMET 4323 58
FMET 4773 58
Transparent Standard Grade FMRTS 4605 68
Heat Resistant Grade FMH 5305 63
FMH 5775 64
Transparent Heat Resistant Grade FMHS 6650 74
Static Dissipative Grade FMND-74602 68
Heat Resistant/Static Dissipative Grade FMND 7605 72
Testing Method JIS K7161-2-1B/50
Nominal Tensile Strain at Break
Unit %
Standard Grade FMET 4323 13
FMET 4773 13
Transparent Standard Grade FMRTS 4605 9
Heat Resistant Grade FMH 5305 20
FMH 5775 28
Transparent Heat Resistant Grade FMHS 6650 12
Static Dissipative Grade FMND-74602 8
Heat Resistant/Static Dissipative Grade FMND 7605 14
Testing Method JIS K7161-2-1B/50
Charpy Impact Strength (Notched)
Unit KJ/㎡
Standard Grade FMET 4323 3.8
FMET 4773 3.8
Transparent Standard Grade FMRTS 4605 1.6
Heat Resistant Grade FMH 5305 7.2
FMH 5775 5
Transparent Heat Resistant Grade FMHS 6650 1.6
Static Dissipative Grade FMND-74602 1.6
Heat Resistant/Static Dissipative Grade FMND 7605 1.7
Testing Method JIS K7111-1 lepA
Flexural Stress
Unit MPa
Standard Grade FMET 4323 78
FMET 4773 78
Transparent Standard Grade FMRTS 4605 87
Heat Resistant Grade FMH 5305 88
FMH 5775 84
Transparent Heat Resistant Grade FMHS 6650 99
Static Dissipative Grade FMND-74602 87
Heat Resistant/Static Dissipative Grade FMND 7605 93
Testing Method JIS K7171
Flexural Elasticity
Unit MPa
Standard Grade FMET 4323 2900
FMET 4773 2900
Transparent Standard Grade FMRTS 4605 3100
Heat Resistant Grade FMH 5305 3000
FMH 5775 2900
Transparent Heat Resistant Grade FMHS 6650 3300
Static Dissipative Grade FMND-74602 3100
Heat Resistant/Static Dissipative Grade FMND 7605 3000
Testing Method JIS K7171
Temperature of Deflection
Under Load (1.8MPa)
Unit ℃
Standard Grade FMET 4323 73
FMET 4773 73
Transparent Standard Grade FMRTS 4605 63
Heat Resistant Grade FMH 5305 86
FMH 5775 94
Transparent Heat Resistant Grade FMHS 6650 85
Static Dissipative Grade FMND-74602 63
Heat Resistant/Static Dissipative Grade FMND 7605 85
Testing Method JIS K7191
Vicat Sofening Temerature(B)
Unit ℃
Standard Grade FMET 4323 81
FMET 4773 81
Transparent Standard Grade FMRTS 4605 71
Heat Resistant Grade FMH 5305 97
FMH 5775 106
Transparent Heat Resistant Grade FMHS 6650 94
Static Dissipative Grade FMND-74602 71
Heat Resistant/Static Dissipative Grade FMND 7605 94
Testing Method JIS K7206
(140℃-55min)
Dimensional Change on Heating
Vertical
Unit %
Standard Grade FMET 4323 -2*
FMET 4773 -2*
Transparent Standard Grade FMRTS 4605 -3
Heat Resistant Grade FMH 5305 -4
FMH 5775 -4
Transparent Heat Resistant Grade FMHS 6650 -5
Static Dissipative Grade FMND-74602 -3
Heat Resistant/Static Dissipative Grade FMND 7605 -5
Testing Method JIS K6745
Horizontal
Unit %
Standard Grade FMET 4323 -1*
FMET 4773 -1*
Transparent Standard Grade FMRTS 4605 -1
Heat Resistant Grade FMH 5305 -1
FMH 5775 -1
Transparent Heat Resistant Grade FMHS 6650 1
Static Dissipative Grade FMND-74602 -1
Heat Resistant/Static Dissipative Grade FMND 7605 -1
Testing Method JIS K6745
Linear Thermal Expansion Coefficient
Unit ×10-5・K-1
Standard Grade FMET 4323 6.7
FMET 4773 6.7
Transparent Standard Grade FMRTS 4605 6.4
Heat Resistant Grade FMH 5305 6.5
FMH 5775 6.5
Transparent Heat Resistant Grade FMHS 6650 6.1
Static Dissipative Grade FMND-74602 6.4
Heat Resistant/Static Dissipative Grade FMND 7605 6.1
Testing Method JIS K7197
Total Light Transmission
Unit %
Standard Grade FMET 4323
FMET 4773
Transparent Standard Grade FMRTS 4605 78
Heat Resistant Grade FMH 5305
FMH 5775
Transparent Heat Resistant Grade FMHS 6650 71
Static Dissipative Grade FMND-74602 75
Heat Resistant/Static Dissipative Grade FMND 7605 63
Testing Method JIS K7361-1

* :
These are a series of test results for products that are less than 15mm thickness.
